nStoring Inverter set values in the Digital Operator (READ)
To store Inverter set values in the Digital Operator, make the settings using the following method. Set o3-02
(Read permitted selection) to 1 (read permitted).
An error may occur while saving to memory. If an error is displayed, press any key to cancel the error display
and return to the o3-01 display. Error displays and their meanings are shown below. (Refer to Chapter 7
Errors when Using Digital Operator Copy Function.)
Select READ Permitted
Prevent overwriting the data stored in EEPROM in the Digital Operator by mistake. With o3-02 set to 0, if you
set o3-01 to 1, and perform the write operation, PrE will be displayed on the Digital Operator, and the write
operation will be stopped.
Table 6.6 READ Function Procedure
Step
No.
Digital Operator Display Explanation
1
Press the Menu Key, and select advanced pro-
gramming mode.
2
Press the ENTER Key, and select the parame-
ters monitor display.
3
Display o3-01 (Copy Function Selection) using
the Increment Key and Decrement Key.
4
Press the ENTER Key, and select the parame-
ters setting display.
5
Change the set value to 1 using the Increment
Key.
6
Set the changed data using the ENTER Key.
The READ function will start.
7
If the READ function ends normally, End is
displayed on the Digital Operator. Parameter
o3-01 is automatically reset to 0, and then the
display returns to o3-01.
Error Display Meaning
You are attempting to set o3-01 to 1 while o3-02 is set to 0.
Read data length mismatch or read data error.
Tried to write parameters to EEPROM on the Digital Operator, but unable to perform write opera-
tion.
DRIVE QUICK
VERIFY
AUTO
TUNING
ADV
DRIVE QUICK
VERIFY
ADV
AUTO
TUNING
DRIVE QUICK
VERIFY
ADV
AUTO
TUNING
DRIVE QUICK
VERIFY
ADV
AUTO
TUNING
DRIVE QUICK
VERIFY
ADV
AUTO
TUNING
DRIVE QUICK
VERIFY
ADV
AUTO
TUNING
