T
roubleshooting
7
-
2
5
nIncorrect
operation
due
to
sneak
current.
The
Inverter
input
can
become
indefinitely
ON
due
to
an
unwanted
current
path
in
the
control
section
output.
If,
in
the
wiring
diagram
shown
below,
the
output
power
supply
for
the
control
section
is
lower
than
24
VDC
or
the
power
supply
is
OFF,
current
will
flow
as
shown
by
the
arrows
and
the
Inverter
input
will
operate.
If
this
occurs,
insert
a
diode
at
section
A
in
the
diagram.
S1 7
SC
24 V
GND
Control device (Output Unit)
Inverter (control input)
Section A
