Omron SYSDRIVE 3G3RV Series

9
-
10
Wiring Example
A wiring example for a Scaling Meter is shown below.
Dimensions
The dimensions of a Scaling Meter are given below.
Inside Inverter
MCCB
Analog output
3-phase
power
supply
Inverter
Analog
monitor
Display LED Size
Weight: 200 g
Recommended Panel
Cutout Dimensions
