O
ptions and Peripheral Devices
9
-
1
3
Dimensions
The
dimensions
of
a
Braking
Unit
are
given
below.
Four, M4
mounting
holes
Mounting direction
Up
Three, wire pullout holes
(with 22-mm-dia. rubber bushings)
