n DC Reactor
A
DC
Reactor
is
used
to
control
harmonics
generated
by
the
Inverter.
It
is
more
effective
than
and
can
be
used
in
combination
with
an
AC
Reactor.
It
is
also
used
to
increase
the
power
factor.
Models and Application
The
standard
models
of
DC
Reactors
are
listed
below.
Inverter DC Reactor
Voltage
Class
Max. Appli-
cable Motor
Capacity
(kW)
Model No.
Rated
Voltage
(V)
Rated
Current
(A)
Inductance
(mH)
Loss
(W)
200-V
Class
0.4/0.75 3G3HV-PUZDAB5.4A8MH
DC800
5.4 8 8
1.5
to
3.7 3G3HV-PUZDAB18A3MH 18 3 18
5.5/7.5 3G3HV-PUZDAB36A1MH 36 1 22
11/15
3G3HV-
PUZDAB72A0.5MH
72 0.5 29
18.5
3G3HV-
PUZDAB90A0.4MH
90 0.4 45
400-V
Class
0.4/0.75
3G3HV-
PUZDAB3.2A28MH
DC800
3.2 28 9
1.5
to
2.2
3G3HV-
PUZDAB5.7A11MH
5.7 11 11
3.7
3G3HV-
PUZDAB12A6.3MH
12 6.3 16
5.5/7.5
3G3HV-
PUZDAB23A3.6MH
23 3.6 27
11/15
3G3HV-
PUZDAB33A1.9MH
33 1.9 26
18.5
3G3HV-
PUZDAB47A1.3MH
47 1.3 42
