Omron SYSDRIVE 3G3RV Series User Manual

I
nstalling and Wiring Option Cards
2
-
4
9
n3G3FV-PPGB2
The terminal specifications for the 3G3FV-PPGB2 are given in the following table.
n3G3FV-PPGD2
The terminal specifications for the 3G3FV-PPGD2 are given in the following table.
*5 VDC and 12 VDC cannot be used at the same time.
Table 2.26 3G3FV-PPGB2 Terminal Specifications
Terminal No. Contents Specifications
TA1
1
Power supply for pulse generator
12 VDC (±5%), 200 mA max.
20 VDC (GND for power supply)
3
A-phase pulse input terminal
H: +8 to 12 V
L: +1 V max.
(Maximum response frequency: 30 kHz)
4Pulse input common
5
B-phase pulse input terminal
H: +8 to 12 V
L: +1 V max.
(Maximum response frequency: 30 kHz)
6Pulse input common
TA2
1
A-phase monitor output terminal
Open collector output, 24 VDC, 30 mA max.
2A-phase monitor output common
3
B-phase monitor output terminal
Open collector output, 24 VDC, 30 mA max.
4 B-phase monitor output common
TA3 (E) Shield connection terminal -
Table 2.27 3G3FV-PPGD2 Terminal Specifications
Terminal No. Contents Specifications
TA1
1
Power supply for pulse generator
12 VDC (±5%), 200 mA max.*
20 VDC (GND for power supply)
35 VDC (±5%), 200 mA max.*
4Pulse input + terminal
Line driver input (RS-422 level input)
Maximum response frequency: 300 kHz
5Pulse input - terminal
6 Common terminal -
7Pulse monitor output + terminal
Line driver output (RS-422 level output)
8Pulse monitor output - terminal
TA2 (E) Shield connection terminal -
