196
Number of bits transferred
8 bits
Example 2 When CIO 000000 is ON in the following example, 24 bits beginning with bit 12
of D00200 are transferred to D00500 (beginning with bit 08), as specified by the
contents of D00100.
Address Instruction Operands
00000 LD 000000
00001 XFRB(038)
D00000
D00200
D00500
Number of bits transferred
24 bits
Data Movement Instructions Section 5-15
(038)
XFRB D00000 D00200 D00500
0000
00
