ng
Instructions 284 284 285 169 170 170
Speed
Basic
instructions (ms)
0.15 to 0.45 0.125 to 0.375 0.125 to 0.375 0.15 to 0.45 0.125 to 0.375 0.125 to 0.375
Other
instructions (ms)
0.6 to 9.9 0.5 to 8.25 0.5 to 8.25 0.6 to 9.9 0.5 to 8.25 0.5 to 8.25
Program capacity 30K words 30K words 62K words 30K words 62K words 62K words
Local I/O capacity 512 pts 1,024 pts 2,048 pts 512 pts 1,024 pts 2,048 pts
Remote
SYSMAC BUS/2 1,024 pts 2,048 pts 2,048 pts 1,024 pts 2,048 pts 2,048 pts
I/O
capacity
SYSMAC BUS 512 pts 1,024 pts 2,048 pts 512 pts 1,024 pts 1,024 pts
DM Area 8K words 24K words 24K words 8K words 24K words 24K words
Expansion DM Area Not supported Not supported
32K words
each for 8
banks
Not supported
32K words
each for 8
banks
32K words
each for 8
banks
Timers 512 1,024 1,024 512 1,024 1,024
Counters 512 1,024 1,024 512 1,024 1,024
SFC steps None None None 512 1,024 1,024
Step Flags None None None 512 1,024 1,024
Transition Flags None None None 512 1,024 1,024
1-13 Improved Specifications
1-13-1 Upgraded Specifications
The following improvements were made December 1992 and are applicable to
all CV500-CPU01-E and CV1000-CPU01-E CPUs with lot numbers in which the
rightmost digit is 3 (3) or higher.
1, 2, 3...
1. The MLPX(110) (4-TO-16 DECODER) instruction has been improved to
also function as a 8-to-256 decoder and the DMPX(111) (16-TO-4 ENCOD-
ER) instruction has been improved to also function as a 256-to-8 encoder.
To enable this improvement, the digit designator (Di) has been changed as
shown below. Refer to
5-17-8 DATA DECODER – MLPX(110)
and
5-17-9
DATA ENCODER – DMPX(111)
for details on these instructions.
Specifies the first digit to be converted
4-to-16/16-to-4: 0 to 3
8-to-256/256-to-8: 0 or 1
Number of digits to be converted
4-to-16/16-to-4: 0 to 3 (1 to 4 digits)
8-to-256/256-to-8: 0 or 1 (1 or 2 digits)
Process
0: 4-to-16/16-to-4
1: 8-to-256/256-to-8
Digit number: 3210
0
2. The following operating parameter has been added to the PC Setup. Refer
to
Section 7 PC Setup
for details on the PC Setup.
JMP(004) 0000 Processing
Y: Enable multiple usage (default)
N: Disable multiple usage
Improved Specifications Section 1-13
