The power interruption time is output to words A012 and A013, and the number
of power interruptions is output to word A014.
3-6-9 CVSS/SSS Flags
Word A008 contains flags that indicate the status of commands and instructions
performed with the CVSS/SSS.
Bit A00807 is turned ON when the Stop Monitor is used from the CVSS/SSS,
and is turned OFF when it is completed.
Bit A00808 is turned ON when the execution time has been measured with
MARK(174) instructions with the CVSS/SSS.
Bit A00809 is turned ON when the differentiate monitor condition has been
established with the CVSS/SSS.
Bit A00810 is turned ON when the Stop Monitor operation has been com-
pleted with the CVSS/SSS.
Bit A00811 is turned ON when one of the trigger conditions has been estab-
lished during execution of a Data or Program Trace with the CVSS/SSS.
Bit A00812 is turned ON upon when the sampling of a region of trace
memory has been completed during execution of a Data or Program Trace
with the CVSS/SSS.
Bit A00813 is turned ON when a Data or Program Trace is executed with the
CVSS/SSS, and is turned OFF when it is completed.
The Trigger conditions are established when bit A00814 is turned ON by one
of trigger conditions of a Data or Program Trace of the CVSS/SSS.
Bit A00815 is turned ON to start a Data Trace.
3-6-10 Start-up Time
Words A010 and A011 contain the start-up time, in BCD format, as shown in the
following table. The start-up time is updated every time the power is turned ON.
Word Bits Contents Possible values
A010 00 to 07 Seconds 00 to 99
08 to 15 Minutes 00 to 59
A011 00 to 07 Hours 00 to 23 (24-hour system)
08 to 15 Day of month 01 to 31 (adjusted by month and for leap year)
3-6-11 Power Interruption Time
Words A012 and A013 contain, in BCD format, the time at which power was in-
terrupted, as shown in the following table. The power interruption time is up-
dated every time the power is interrupted.
Word Bits Contents Possible values
A012 00 to 07 Seconds 00 to 99
08 to 15 Minutes 00 to 59
A013 00 to 07 Hours 00 to 23 (24-hour system)
08 to 15 Day of month 01 to 31 (adjusted by month and for leap year)
Stop Monitor Flag (A00807)
Execution Time Measured
Flag (A00808)
Differentiate Monitor
Completed Flag (A00809)
Stop Monitor Completed
Flag (A00810)
Trace Trigger Monitor Flag
(A00811)
Trace Completed Flag
(A00812)
Trace Busy Flag (A00813)
Trace Start Bit (A00814)
Sampling Start Bit (A00815)
Auxiliary Area Section 3-6
