Omron SYSMAC CV Series - Double Bcd-To-Double Binary: Binl(102)

(102)
BINL 0010 D00200
0000
00
221
0D00150 F F F
0D00160 0 0 0
0D00150 F F F
4D00160 0 9 5
Before
execution
After
execution
The bit contents of words D00150 and D00160 after execution are:
0000111111111111
0FFF
D00150
0100000010010101
4095
D00160
5-17-3 DOUBLE BCD-TO-DOUBLE BINARY: BINL(102)
(102)
BINL S R
R: Result word CIO, G, A, DM
S: Source word CIO, G, A, T, C, DM
Operand Data AreasLadder Symbol
Variations
j BINL(102)
When the execution condition is OFF, BINL(102) is not executed. When the
execution condition is ON, BINL(102) converts an 8-digit BCD number in S and
S+1 into 32-bit binary data, and outputs the converted data to R and R+1.
S + 1 S
R + 1 R
BCD
Binary
S and S+1 must be BCD.
Note Refer to page 115 for general precautions on operand data areas.
Flags ER (A50003): Content of S or S+1 is not BCD.
Content of *DM word is not BCD when set for BCD.
EQ (A50006): 0 has been placed in R.
N (A50008): OFF
Example When CIO 000000 is ON in the following example, the BCD value in CIO 0010
and CIO 0010 is converted to a hexadecimal (binary) value and stored in
D00200 and D00201.
Address Instruction Operands
00000 LD 000000
00001 BINL(102)
0010
D00200
Description
Precautions
Conversion Instructions Section 5-17
