Omron SYSMAC CV Series - Floating to 16-Bit: Fix(450)

296
100
100
Calculations
Distance r =
Angle θ = tan
–1
(
y
x
)
Example
Distance r = = 141.4214
Angle θ = tan
–1
(
)
= 45.0
DM Contents
D00000 0 1 0 0
D00001 0 1 0 0
x
y
D00100 0 1 4 1
D00101 0 0 4 5
r
θ
x
2
 y
2

100
2
 100
2

1, 2, 3... 1. This instruction clears (i.e., sets to “0”) D00100 and D00101 so that the dis-
tance and angle result can be output to those words.
2. This section of the program converts the data from BCD to floating-point.
a) The data area from D00200 onwards is used as a work area.
b) First BIN(100) is used to temporarily convert the BCD data to binary
data, and then FLT(452) is used to convert the binary data to floating-
point data.
c) The value of x that has been converted to floating-point data is output to
to D00203 and D00202.
d) The value of y that has been converted to floating-point data is output to
to D00205 and D00204.
3. In order to find the distance r, Floating-point Math Instructions are used to
calculate the square root of x
2
+y
2
. The result is then output to D00213 and
D00212 as floating-point data.
4. In order to find the angle θ, Floating-point Math Instructions are used to cal-
culate tan
–1
(y/x). ATAN(465) outputs the result in radians, so DEG(459) is
used to convert to degrees. The result is then output to D00219 and D00218
as floating-point data.
5. The data is converted back from floating-point to BCD.
a) First FIX(450) is used to temporarily convert the floating-point data to
binary data, and then BCD(101) is used to convert the binary data to
BCD data.
b) The distance r is output to to D00100.
c) The angle θ is output to to D00101.
5-21-1 FLOATING TO 16-BIT: FIX(450)
(450)
FIX S R
Ladder Symbol
Variations
↑FIX(450)
Operand Data Areas
S: First source word CIO, G, A, T, C, #, DM
R: Result word CIO, G, A, DM, DR, IR
When the execution condition OFF, FIX(450) is not executed. When the execu-
tion condition is ON, FIX(450) converts the 32-bit floating-point content of S and
S+1 to 16-bit binary data, and places the result in R.
S+1 S
R
Floating-point data (32 bits)
Binary data (16 bits)
Description
(CVM1 V2)
Floating-point Math Instructions
Section 5-21
