Omron SYSMAC CV Series - Double Logical And: Andl(134)

(133)
XNRW 00100 0020 D00200
0000
00
(134)
ANDL 0010 0020 D00200
0000
00
344
Flags ER (A50003): Content of *DM word is not BCD when set for BCD.
EQ (A50006): The result is 0.
N (A50008): Shows the status of bit 15 of R after execution.
Example When CIO 000000 is ON in the following example, the logical exclusive NOR is
taken of corresponding bits in CIO 0010 and CIO 0020 and the results is placed
in corresponding bits of D00200.
Address Instruction Operands
00000 LD 000000
00001 XNRW(133)
0010
0020
D0020
10 0110 0110 0110 01
15 00
01 0101 0101 0101 01
00 1100 1100 1100 11
15 00
15 00
CIO 0010
CIO 0020
D00200
5-25-5 DOUBLE LOGICAL AND: ANDL(134)
Variations
j ANDL(134)
(134)
ANDL I
1
I
2
R
I
2
: Input 2 CIO, G, A, T, C, #, DM
R: Result word CIO, G, A, DM
I
1
: Input 1 CIO, G, A, T, C, #, DM
Operand Data AreasLadder Symbol
When the execution condition is OFF, ANDL(134) is not executed. When the ex-
ecution condition is ON, ANDL(134) logically AND’s corresponding bits of I
1
and
I
1
+1 with I
2
and I
2
+1 and places the result in R and R+1.
Refer to page 115 for general precautions on operand data areas.
Flags ER (A50003): Content of *DM word is not BCD when set for BCD.
EQ (A50006): The result is 0.
N (A50008): Shows the status of bit 15 of R+1 after execution.
Example When CIO 000000 is ON in the following example, the logical AND is taken of
corresponding bits in CIO 0010 to CIO 0011 and CIO 0020 to CIO 0020 and the
results is placed in corresponding bits of D00200 and D00201.
Address Instruction Operands
00000 LD 000000
00001 ANDL(134)
0010
0020
D0020
Description
Precautions
Logic Instructions Section 5-25
