5-23-4 BCD SQUARE ROOT: ROOT(140)
(140)
ROOT Sq R
R: Result word CIO, G, A, DM, DR, IR
Sq: 1
st
source word CIO, G, A, T, C, #, DM
Operand Data AreasLadder Symbol
Variations
j ROOT(140)
When the execution condition is OFF, ROOT(140) is not executed. When the
execution condition is ON, ROOT(140) computes the square root of the 8-digit
content of Sq and Sq+1 and places the result in R. The fractional portion is trun-
cated.
R
Sq+1 Sq
Sq must be BCD.
Note Refer to page 115 for general precautions on operand data areas.
Flags ER (A50003): Sq or the content of *DM word is not BCD when set for BCD.
EQ (A50006): ON when the result is 0.
Description
Precautions
Special Math Instructions Section 5-23
