0000
A5000010
(281)
WR2 #0010 D00300 0002
Equals Flag
0010
01
01
01 06
412
Example When CIO 000001 is ON in the following example, the 16 words beginning with
D00300 are transferred in order through CIO 0002 and are written in order to
words 00 through 0F in the Special I/O Unit‘s memory area.
Address Instruction Operands
00000 LD 000001
00001 OR 001001
00002 WR2(281)
#0010
D00300
0002
00003 AND NOT A50006
00004 OUT 001001
0 0
Number of words to be written: 16
C: Control Word Contents
Beginning address for writing: word 00
1 0 (Binary data)
Number of words
to be written
PC Memory
Beginning address
for writing
Words allocated to
Special I/O Unit
S: First source word
D: Destination word
Special I/O Unit Memory
Special I/O Instructions Section 5-35
