C:Execute process Asynchronous
control 2
I:I/O interrupt Nesting
D:Power OFF interrupt Disable
A:Dup action process Error
T:Step timer Set to 0.1 s
J:Startup trace Don’t start trace.
B:*DM BIN/BCD BCD
P:Multiple use of JMP000 Enabled
E:Compare error process Run after error
H:Host link B:Baud rate 9600 bps
S:Stop bit 2 bits
P:Parity Even
D:Data bits 7 bits
G:Unit # Unit number 0
I:CPU bus link Don’t use CPU Bus Link.
J:Scheduled interrupt 10.0 ms
K:1st Rack addr (First words for local racks) 0 for CPU Rack
L:Group 1,2 1st addr
(First words for SYSMAC BUS/2 Slaves)
RM0 RM1 RM2 RM3
Group 1:CIO 0200CIO 0400CIO 0600CIO 0800
Group 2:CIO 0250CIO 0450CIO 0650CIO 0850
M:Trans I/O addr (First words for I/O
Terminals)
RM0 RM1 RM2 RM3
CIO 2300 CIO2332 CIO 2364 CIO2396
RM4
RM5 RM6 RM7
CIO 2428 CIO 2460 CIO 2492 CIO 2524
N:Group 3, RT 1st addr
(First words for group-3 Slave Racks)
Group 3 (SYSMAC BUS/2):
RM0
RM1 RM2 RM3
CIO 0300 CIO 0500 CIO 0700 CIO 0900
Words allocated to Units in order under each Master.
RT (SYSMAC BUS):
Defaults for SYSMAC BUS Slaves are the same as for I/O Terminals
(see above). Words allocated to Units in order under each Master.
O:CV–SIOU 1st addr Not used at present.
P:Power break (Momentary power interruption
time)
0 ms
Q:Cycle time Cycle variable
R:Watch cycle time (Cycle time monitoring
time)
1,000 ms
S:Error log 20 records in A100 through A199
T:IOIF, RT display (Slave display modes at
startup)
Mode 1
PC Setup Default Settings Section 7-3
