Appendix AInstruction Set
517
Note Instructions marked with an asterisk (*) are supported by version-2 CVM1 CPUs only.
Special Timer and SFC Control Instructions
Code Mnemonic Name
120 TTIM ACCUMULATIVE TIMER
121 TIML DOUBLE TIMER
122 MTIM MULTI-OUTPUT TIMER
123 TCNT TRANSITION COUNTER
124
TSR(j)
READ STEP TIMER
125
TSW(j)
WRITE STEP TIMER
Logical Instructions
Code Mnemonic Name
130
ANDW(j)
LOGICAL AND
131
ORW(j)
LOGICAL OR
132
XORW(j)
EXCLUSIVE OR
133
XNRW(j)
EXCLUSIVE NOR
134
ANDL(j)
DOUBLE LOGICAL AND
135
ORWL(j)
DOUBLE LOGICAL OR
136
XORL(j)
DOUBLE EXCLUSIVE OR
137
XNRL(j)
DOUBLE EXCLUSIVE NOR
138
COM(j)
COMPLEMENT
139
COML(j)
DOUBLE COMPLEMENT
Special and Time-related Instructions
Code Mnemonic Name
140
ROOT(j)
BCD SQUARE ROOT
141
FDIV(j)
FLOATING POINT
DIVIDE(BCD)
142
APR(j)
ARITHMETIC PROCESS
143
SEC(j)
HOURS-TO-SECONDS
144
HMS(j)
SECONDS-TO-HOURS
145
CADD(j)
CALENDAR ADD
146
CSUB(j)
CALENDAR SUBTRACT
Subroutine and Interrupt Instructions
Code Mnemonic Name
150 SBN SUBROUTINE ENTER
151
SBS(j)
SUBROUTINE CALL
152 RET SUBROUTINE RETURN
153
MSKS(j)
INTERRUPT MASK
154
CLI(j)
CLEAR INTERRUPT
155
MSKR(j)
READ MASK
156
MCRO(j)*
MACRO
Table Data Processing Instructions
Code Mnemonic Name
160
SSET(j)
SET STACK
161
PUSH(j)
PUSH ONTO STACK
162
LIFO(j)
LAST IN FIRST OUT
163
FIFO(j)
FIRST IN FIRST OUT
164
SRCH(j)
DATA SEARCH
165
MAX(j)
FIND MAXIMUM
166
MIN(j)
FIND MINIMUM
167
SUM(j)
SUM
Debugging, Special, Error Processing and
Time-related Instructions
Code Mnemonic Name
170 TRSM TRACE MEMORY
171
EMBC(j)
SELECT EM BANK
172
CCL(j)
LOAD FLAGS
173
CCS(j)
SAVE FLAGS
174 MARK MARK TRACE
175
REGL(j)
LOAD REGISTER
176
REGS(j)
SAVE REGISTER
177 FPD* FAILURE POINT
DETECTION
178
WDT(j)*
MAXIMUM CYCLE TIME
EXTEND
179
DATE(j)*
CLOCK COMPENSATION
File Memory, Basic I/O, and Special I/O
Instructions
Code Mnemonic Name
180
FILR(j)
READ DATA FILE
181
FILW(j)
WRITE DATA FILE
182
FILP(j)
READ PROGRAM FILE
183
FLSP(j)
CHANGE STEP PROGRAM
184
IORF(j)
I/O REFRESH
187
IOSP(j)
DISABLE ACCESS
188 IORS ENABLE ACCESS
189
IODP(j)
I/O DISPLAY
190 READ I/O READ
191 WRIT I/O WRITE
192
SEND(j)
NETWORK SEND
193
RECV(j)
NETWORK RECEIVE
194
CMND(j)
DELIVER COMMAND
195
MSG(j)
MESSAGE
