Omron SYSMAC CV Series User Manual

Appendix BError and Arithmetic Flag Operation
571
Instructions A50010
(UF)
A50009
(OF)
A50008
(N)
A50007
(LE)
A50006
(EQ)
A50005
(GR)
A50004
(CY)
A50003
(ER)
ADB(080)
ON/OFF ON/OFF ON/OFF ON/OFF ON/OFF ON/OFF
SBB(081)
MLB(082)
ON/OFF ON/OFF ON/OFF
DVB(083)
ADBL(084)
ON/OFF ON/OFF ON/OFF ON/OFF ON/OFF ON/OFF
SBBL(085)
MLBL(086)
ON/OFF ON/OFF ON/OFF
DVBL(087)
INC(090)
ON/OFF ON/OFF
DEC(091)
INCB(092)
ON/OFF ON/OFF ON/OFF
DECB(093)
INCL(094)
ON/OFF ON/OFF
DECL(095)
INBL(096)
ON/OFF ON/OFF ON/OFF
DCBL(097)
BIN(100) ON/OFF ON/OFF OFF
BCD(101) ON/OFF ON/OFF
BINL(102) ON/OFF ON/OFF OFF
BCDL(103) ON/OFF ON/OFF
NEG(104)
ON/OFF ON/OFF ON/OFF
NEGL(105)
SIGN(106)
MLPX(110)
ON/OFF
DMPX(111)
SDEC(112)
ASC(113)
BCNT(114)
ON/OFF ON/OFF
LINE(115)
COLM(116)
HEX(117)*
ON/OFF
TTIM(120)
TIML(121)
MTIM(122)
TCNT(123)
TSR(124)
TSW(125)
ANDW(130)
ON/OFF ON/OFF ON/OFF
ORW(131)
XORW(132)
XNRW(133)
ANDL(134)
ORWL(135)
XORL(136)
XNRL(137)
COM(138)
COML(139)
Note “ON/OFF” means that the flag is affected by the result of instruction execution.
