Appendix BError and Arithmetic Flag Operation
574
Instructions A50010
(UF)
A50009
(OF)
A50008
(N)
A50007
(LE)
A50006
(EQ)
A50005
(GR)
A50004
(CY)
A50003
(ER)
SIN(460)*
ON/OFF ON/OFF ON/OFF OFF OFF
COS(461)*
TAN(462)* ON/OFF ON/OFF ON/OFF ON/OFF OFF
ASIN(463)* ON/OFF ON/OFF ON/OFF OFF OFF
ACOS(464)* ON/OFF ON/OFF OFF OFF OFF
ATAN(465)* ON/OFF ON/OFF ON/OFF OFF OFF
SQRT(466)* ON/OFF ON/OFF OFF ON/OFF OFF
EXP(467)* ON/OFF ON/OFF OFF ON/OFF ON/OFF
LOG(468)* ON/OFF ON/OFF ON/OFF ON/OFF OFF
TIMW<013>*
ON/OFF
CNTW<014>*
TMHW<015>*
Note “ON/OFF” means that the flag is affected by the result of instruction execution.
