Appendix DData Areas
580
Word(s) FunctionBit(s)
A302 00 to 15 CPU Bus Unit Initializing Flags
A303 to A305 00 to 15 Not used.
A306 00 Start Input Wait Flag
01 I/O Verification Error Wait Flag
02 SYSMAC BUS Terminator Wait Flag
03 CPU Bus Unit Initializing Wait Flag
04 to 07 Not used.
08 to 11 Connected Device Code 2: GPC
3: Programming Console
12 to 14 Not used.
15 Peripheral Connected Flag
A307 00 to 07 Peripheral Connected Flags for RT #0 to RT #7 of RM/2 #0
08 to 15 Peripheral Connected Flags for RT #0 to RT #7 of RM/2 #1
A308 00 to 07 Peripheral Connected Flags for RT #0 to RT #7 of RM/2 #2
08 to 15 Peripheral Connected Flags for RT #0 to RT #7 of RM/2 #3
A309 00 to 15 Peripheral Device Cycle Time (binary)
A310 to A325 00 to 15 CPU Bus Unit Service Interval (binary)
A326 to A342 00 to 15 Not used.
A343 00 to 02 Memory Card Type
03 to 06 Not used.
07 Memory Card Format Error Flag
08 Memory Card Transfer Error Flag
09 Memory Card Write Error Flag
10 Memory Card Read Error Flag
11 FIle Missing Flag
12 Memory Card Write Flag
13 Memory Card Instruction Flag
14 Accessing Memory Card Flag
15 Memory Card Protected Flag
A344 to 345 00 to 15 Not used.
A346 00 to 15 Number of Words Remaining to transfer to memory card for a file read/write instruction
(BCD)
A347 to A399 00 to 15 Not used.
A400 00 to 15 Error Code
A401 00 to 05 Not used.
06 FALS Error Flag
07 SFC Fatal Error Flag
08 Cycle Time Too Long Flag
09 Program Error Flag
10 I/O Setting Error Flag
11 Too Many I/O Points Flag
12 CPU Bus Error Flag
13 Duplication Error Flag
14 I/O Bus Error Flag
15 Memory Error Flag
