B
System Specifications
These sections describe specifications for Exadata Server X10M.
Server Physical Specifications
The following table lists physical specifications for Exadata Server X10M.
Table B-1 Physical Specifications
Dimension Server Specification Measurements
Height 2-rack unit (2U) nominal 86.9 mm (3.42 inches)
Width Server chassis 445 mm (17.52 inches)
Depth Maximum overall 756 mm (29.76 inches)
Weight Fully populated server 34 kg (76 lbs)
Dimensions do not include PSU handles.
Electrical Requirements
The server uses high-line AC power. The server can operate effectively over a range of
voltages and frequencies.
The following table contains the power supply specifications for Exadata Server X10M.
Note:
The power dissipation numbers listed in the following table are the maximum rated
power numbers for the power supply used in the server. The numbers are not a
rating of the actual power consumption of the server. For up-to-date information
about server power consumption, go to Oracle Power Calculator .
Table B-2 Electrical Requirements
Parameter Exadata Server X10M Specification
Electrical ratings 200-240V~, 10A, 50/60Hz (x2)
Voltage (nominal) 200-240 VAC
Input current (maximum) 10.0A at 200-240 VAC
Frequency (nominal) 50/60 Hz (47-63 Hz range)
Maximum power consumption 1400W at AC 200V-240V
B-1
