Caution:
Before you install the optional cable management arm verify that the
server is securely mounted in the rack and that the slide-rail locks are
engaged with the mounting brackets.
Install the Cable Management Arm (Optional)
Follow this procedure to install the cable management arm (CMA), which you can use
to manage cables connected to the back of the server.
Note:
Before you install the CMA, ensure that the right-angle AC power cables are
long enough to connect to the rackmounted servers when routed through the
CMA.
1. Unpack the CMA, which contains the following components.
Appendix C
Rackmounting the Server
C-16
