Oracle Exadata X10M - Processor Components

Table E-5 (Cont.) Drive Components
Component Name
(Oracle ILOM CLI
Targets)
IPMI Type Description Values (if applicable)
/SYS/MB/SSDR[0-1]/
SSD[0-1]
FRU Internal SSD drive FRU
/SYS/MB/SSDR[0-1]/
SSD[0-1]/PRSNT
Discrete
sensor
SSD drive presence (1 SSD per riser on
2U) (Hidden)
01h-ENTITY_ABSENT
02h-ENTITY_PRESENT
/SYS/MB/SSDR[0-1]/
SSD[0-1]/STATE
State
sensor
SSD drive state 04h-INSTALLED
20h-SLOT POWER OFF
/SYS/MB/SSDR[0-1]/
SSD[0-1]/NVME
FRU Internal SSD that is NVM Express FRU
/SYS/MB/SSDR[0-1]/
SSD[0-1]/NVME/
PRSNT
Discrete
sensor
Indicates the SSD is PCIe (NVMExpress) 01h-ENTITY_ABSENT
02h-ENTITY_PRESENT
Processor Components
The following table lists the processor (CPU) components.
Table E-6 Processor Components
Component Name
(Oracle ILOM CLI
Targets)
IPMI Type Description Values (if applicable)
/SYS/MB/P[0- x ]
FRU Host CPU FRU
/SYS/MB/P[0-1 ]/
PRSNT
Discrete
sensor
Host CPU is present. 01h-ENTITY_PRESENT
02h-ENTITY_ABSENT
/SYS/MB/P[0- x ]/
SERVICE
Indicator Host CPU Fault-Service Required LED Color: Amber
Location: Motherboard
Off: Normal
On: Processor was diagnosed
as faulty.
Memory Device Components
The following table lists the memory device components.
Table E-7 Memory Device Components
Component Name
(Oracle ILOM CLI
Targets)
IPMI Type Description Values (if applicable)
/SYS/MB/P[0- x ]/
D[0-11]
FRU Host CPU DIMM FRU
Appendix E
Processor Components
E-6
