Oracle Exadata X10M User Manual

Table E-2 Power Unit Components
Component Name
(Oracle ILOM CLI
Targets)
IPMI Type Description Values (if applicable)
/SYS/PDB
FRU Power distribution board FRU
/SYS/PS[0-1]
FRU Power supply FRU
/SYS/PS[0-1]/PRSNT
Discrete
sensor
Power supply is present. (Hidden) 01h-ENTITY_ABSENT
02h-ENTITY_PRESENT
/SYS/PS[0-1]/STATE
State
sensor
Power supply state sensor
Multistate, power supply sensor type, per
IPMI
Presence detected
Failure detected
Predictive failure
Power supply input lost
Power supply input lost or out-
of-range
Power supply input out-of-
range
Configuration error
/SYS/PS[0-1]/P_IN
Threshold
sensor
Input power draw Watts
/SYS/PS[0-1]/P_OUT
Threshold
sensor
Output power Watts
/SYS/PS[0-1]/V_IN
Threshold
sensor
Power supply input voltage Volts
/SYS/PS[0-1]/V_12V
Threshold
sensor
Power supply 12V output voltage Volts
/SYS/PS[0-1]/
V_12V_STBY
Threshold
sensor
Power supply 12V standby output voltage Volts
/SYS/PS[0-1]/T_IN
Threshold
sensor
PSU input temperature Degrees Celsius
/SYS/PS[0-1]/T_OUT
Threshold
sensor
PSU output temperature Degrees Celsius
Cooling Unit Components
The system has six 60-mm fan modules with two fans in each module. The following table
lists the system cooling unit components.
Table E-3 Cooling Unit Components
Component Name
(Oracle ILOM CLI
Targets)
IPMI Type Description Values (if applicable)
/SYS/MB/FM[0-5]
FRU Fan module FRU
/SYS/MB/FM[0-5]/F[0-
x ]
FRU Individual fan
Appendix E
Cooling Unit Components
E-3
