Oracle Exadata X10M - System Firmware Components

Table E-8 (Cont.) System Motherboard Components
Component Name
(Oracle ILOM CLI
Targets)
IPMI Type Description Values (if applicable)
/SYS//SYS/MB/
RISER6/PCIE[6, 8]/
P_ENABLE_STATE
State
Sensor
PCIe slots on Riser 6 Power Enable State 02h-SLOT POWER ENABLED
01h-SLOT POWER DISABLED
/SYS/MB/ROT
FRU Root of Trust FRU
Optional card is present in slot 1 (only
supported slot)
/SYS//SYS/MB/ROT/
PRSNT
Discrete
Sensor
Root of Trust is Present 01h-ENTITY_ABSENT
02h-ENTITY_PRESENT
/SYS/MB/
T_IN_ZONE[0-3]
Threshold
sensor
Cooling zone input temperature sensor Degrees Celsius
/SYS/MB/
T_OUT_ZONE[0-3]
Threshold
sensor
Cooling zone output temperature sensor Degrees Celsius
/SYS/SP
FRU Service processor FRU
/SYS/SP/OK
Indicator SP OK LED
Color: Green
Location: Front panel
On: SP is operating.
Off: SP requires service.
/SYS/SP/NET[0-1]
FRU SP Ethernet FRU
System Firmware Components
The following table lists the system firmware components.
Table E-9 System Firmware Components
Component
Name (Oracle
ILOM CLI
Targets)
IPMI
Type
Description
/SYS/MB/BIOS
FRU BIOS FRU
/SYS/MB/CPLD
FRU Motherboard complex programmable logic device (CPLD)/field programmable gate
array (FPGA) firmware version
Appendix E
System Firmware Components
E-8
