Servicing the Disk Backplane
This section describes how to service the 4-Drive backplane and 12-Drive backplane.
The disk backplane (DBP) is a replaceable component that requires you to power off the
server before servicing. Perform the 4-Drive backplane or 12-Drive backplane procedures.
For more information about replaceable components, see Illustrated Parts Breakdown and
Replaceable Components.
Caution:
Ensure that all power is removed from the server before removing or installing the
disk backplane. You must disconnect the power cables before performing this
procedure.
Caution:
These procedures require that you handle components that are sensitive to
electrostatic discharge. This sensitivity can cause the component to fail. To avoid
damage, ensure that you follow electrostatic discharge safety measures and
antistatic practices. See Electrostatic Discharge Safety.
Remove the 4-Drive Backplane
To remove the storage drive cage and 4-Drive disk backplane (DBP):
1. Prepare the server for service.
a. Power off the server.
See Powering Down the Server.
b. Disconnect the power cords from the power supplies.
See Disconnect Cables From the Server.
c. Extend the server into the maintenance position.
See Extend the Server to the Maintenance Position.
d. Attach an antistatic wrist strap to your wrist, and then to a metal area on the chassis.
See Take Antistatic Measures.
e. Remove the server top cover.
See Remove the Server Top Cover.
f. Remove the air baffle.
See Remove the Air Baffle.
14-1
