Table B-13 480GB, M.2, NVMe Solid State Drive 8214991 Specification
Specification Value
Device name Product Identifier: SAMSUNG MZVL2480HBJD-00A07
Oracle Part Number: 8214991
Device Identification:
PCIe Vendor ID: 0x144D
PCIe Device ID: 0xA80A
Subsystem PCIe Vendor ID: 0x144D
Subsystem ID 0xA812
Manufacturing name Samsung PM9A3 480GB M.2 NVMe Solid-State Drive
Form factors M.2 2280 M key
PCIe interface PCIe Gen4 Interface, Single port x4 lanes
Features NVMe PCIe Gen4 Interface
NVMe-MI
VPD is blank “FFs” as supplied
TCG Opal 2.0 compliant
Product Compliance NVM Express Specification Rev. 1.4
PCI Express Base Specification Rev. 4.0
Enterprise SSD Form Factor Version 1.0a
NVMe-MI Rev 1.1 (excluding VPD data)
Product ecological compliance RoHS
Certifications and declarations cUL, CE, TUV-GS, CB, BSMI, KC, VCCI, Morocco, RCM,
FCC, IC
Table B-14 Drive Usage Information
Attribute Value
Operating temperature (Composite,
as reported via SMART)
0 to 70 degrees Celsius
Non-Operating temperature -40 to 85 degrees Celsius
Maximum temperature (SMART trip) Warning at 77 degrees Celsius (composite). Thermal
throttling in stages until critical 85 degrees Celsius.
Thermal Shutdown at 99 degrees Celsius.
Error rates Uncorrectable Bit Error Rate (UBER): 1 sector per 10^17
bits read
Data retention 3 months powered off at 40 degrees Celsius at end of
rated endurance
Endurance Drive Writes Per Day (DWPD) for 5 years: 1
PBW (at 4KB Random Write): 0.8 PB
Refer to the JEDEC JESD218A standard for SSD device
life and endurance measurement techniques.
Table B-15 Drive Reliability
Attribute Value
Component Design Life (Useful life) 5 years
Appendix B
480GB NVMe M.2 Solid State Drive Specification
B-10
