5. Disconnect the power cord from the failed power supply.
6. Grasp the power supply handle and push the power supply latch to the left.
Open the power supply handle if the handle is folded flush. Open the velcro straps if
present.
7. Pull the power supply out of the chassis.
Caution:
When you remove a power supply, be sure to replace it with another power
supply within 60 seconds; otherwise, the server might overheat due to improper
airflow.
8. Continue to Install a Power Supply.
Install a Power Supply
Caution:
Always replace the failed power supply with the same type model of power supply.
1. Remove the replacement power supply from its packaging, and place it on an antistatic
mat.
2. Align and orient the replacement power supply with the empty power supply slot.
3. Slide the power supply into the slot until it is fully seated.
You will hear an audible click when the power supply fully seats.
Chapter 5
Install a Power Supply
5-3
