Oracle Exadata X10M - Illustrated Parts Breakdown

Callout Description
11 PCIe slot 4 (PCIe 3, x16 electrical interface(1)) Riser 2 x16 connector, x1 Electrical
Gen3, Riser 2
12 PCIe slot 5 (PCIe 5, x16 electrical interface)
13 PCIe slot 6 (PCIe 4, x16 electrical interface) Riser 6 x16 connector, x1 Electrical
Gen3, Riser 6
14 PCIe slot 7 (Blank), Riser 6
15 PCIe slot 8 (PCIe 3, x16 electrical interface (1)) Riser 6
16 LOCATE: Server Locate Button/LED
17 SP: Reset service processor (SP). See Manually Resetting a Server's Service
Processor.
18 NET 0: Network (NET) 1GbE 100/1000BASE-T RJ-45 Gigabit Ethernet (GbE) port
19 NET MGT: Oracle Integrated Lights Out Manager (ILOM) service processor (SP)
network management (NET MGT) 1GbE RJ-45 100/1000BASE-T port
20 USB 3.1 connector
21 SYSTEM: Fault-Service Required: amber; System OK: green. See System status
LEDs
22 SER MGT: Serial management (SER MGT) RJ-45 serial port
See Server Status Indicator LEDs. Single-processor systems: PCIe slots 1-4 are
nonfunctional in single-processor systems.
Related Topics
• Back Panel Connector Locations
• System-Level Status Indicators
Illustrated Parts Breakdown
Identify major components of Exadata Server X10M with 4-Drive Backplane and Exadata
Server X10M with 12-Drive Backplane.
Exadata Server X10M with 4-Drive Backplane
The following figure identifies Exadata Server X10M major components with 4-Drive
backplane.
