Rack Compatibility
The rack into which you install Exadata Server X10M must meet the requirements
listed in the following table. Oracle Rack Cabinet 1242 and Sun Rack II are compatible
with Exadata Server X10M. For information about the racks, see Rackmounting the
Server.
Table C-2 Rack Compatibility
Item Requirement
Structure Four-post rack: (mounting at both front and back) Supported rack
types: square hole (9.5 mm) and round hole (M6 or 1/4-20
threaded only).
Two-post racks are not compatible.
Rack horizontal opening
and unit vertical pitch
Conforms to ANSI/EIA 310-D-1992 or IEC 60297 standards.
Distance between front and
back mounting planes
Minimum 61 cm and maximum 91.5 cm (24 inches to 36 inches).
Clearance depth in front of
front mounting plane
Distance to front cabinet door is at least 2.54 cm (1 inch).
Clearance depth behind
front mounting plane
Distance to back cabinet door is at least 90 cm (35.43 inches)
with the cable management arm, or 80 cm (31.5 inches) without
the cable management arm.
Clearance width between
front and back mounting
planes
Distance between structural supports and cable troughs is at
least 45.6 cm (18 inches).
Minimum clearance for
service access
Clearance, front of server: 123.2 cm (48.5 inches)
Clearance, back of server: 91.4 cm (36 inches)
The following table contains Oracle Rack Cabinet 1242 rack specifications:
Table C-3 Oracle Rack Cabinet 1242 Rack Specifications
Requirement Specification
Usable rack units 42
Height 199.9 cm (78.74 inches)
Width (with side panels) 60 cm (23.62 inches)
Maximum dynamic load 1005 kg (2215 lbs)
The following table contains Sun Rack II Model 1242 and Sun Rack II Model 1042 rack
specifications:
Table C-4 Sun Rack II Model 1242 and Sun Rack II Model 1042 Rack
Specifications
Requirement Specification
Usable rack units 42
Appendix C
Rack Compatibility
C-2
