Table E-7 (Cont.) Memory Device Components
Component Name
(Oracle ILOM CLI
Targets)
IPMI Type Description Values (if applicable)
/SYS/MB/P[0-1 ]/
D[0-11]/PRSNT
Discrete
sensor
Host CPU DIMM is present. 01h-ENTITY_ABSENT
02h-ENTITY_PRESENT
/SYS/MB/P[0- x ]/
D[0-11]/SERVICE
Indicator Host CPU DIMM Fault-Service Required
LED
Color: Amber
Location: Motherboard
Off: Normal
On: DIMM was diagnosed as
faulty.
/SYS/MB/P[0-1]/
D[0-11]/TEMP
Discrete
sensor
Host CPU DIMM temperature sensor
(Hidden)
System Motherboard Components
The following table lists the system motherboard components.
Table E-8 System Motherboard Components
Component Name
(Oracle ILOM CLI
Targets)
IPMI Type Description Values (if applicable)
/SYS/MB
FRU General host system motherboard FRU
/SYS/MB/NET[0 ]
FRU Host Ethernet FRU
/SYS/MB/PCIE[1-9]
FRU PCIe slot
/SYS/MB/PCIE[1-9]/
PRSNT
Discrete
Sensor
PCIe slot is occupied. 01h-ENTITY_ABSENT
02h-ENTITY_PRESENT
/SYS/MB/PCIE[1-9]/
P_ENABLE_STATE
Indicator PCIe slot power indicator 01h-ENTITY_ABSENT
02h-ENTITY_PRESENT
/SYS/MB/RISER[2-6]
FRU PCIe Riser card FRU at Slot 2 and Slot 6
(Database Full Height card configuration)
/SYS/MB/RISER[2-6]/
PRSNT
Discrete
Sensor
PCIe Riser Card at Slot 2 or Slot 6 is
present
01h-ENTITY_ABSENT
02h-ENTITY_PRESENT
/SYS/MB/RISER2/
PCIE[2, 4]
FRU PCIE Slot on RISER2
Slot 2 - x16 CEM slot
Slot 4 - x1 CEM slot for SMART NIC
/SYS//SYS/MB/
RISER2/PCIE[2, 4]/
PRSNT
Discrete
Sensor
Option card inserted into PCIe Slots on
Riser 2
01h-ENTITY_ABSENT
02h-ENTITY_PRESENT
/SYS//SYS/MB/
RISER2/PCIE[2, 4]/
P_ENABLE_STATE
State
Sensor
PCIe slots on Riser 2 Power Enable State 02h-SLOT POWER ENABLED
01h-SLOT POWER DISABLED
/SYS//SYS/MB/
RISER6/PCIE[6, 8]/
PRSNT
Discrete
Sensor
Option card inserted into PCIe Slots on
Riser 6
01h-ENTITY_ABSENT
02h-ENTITY_PRESENT
Appendix E
System Motherboard Components
E-7
