Table E-1 (Cont.) System Chassis Components
Component Name
(Oracle ILOM CLI
Targets)
IPMI Type Description Values (if applicable)
/SYS/TEMP_FAULT
Indicator Temperature Fault LED Color: Amber
Location: Front panel
Off: Normal
On: Chassis overtemp fault
/SYS/OK
Indicator System OK LED Color: Green
Location: Front and back panels
Off: Power is off.
Standby blink: Host is off,
awaiting Power On.
Slow blink: Startup sequence
initiated on host.
On: Host is booting OS or
running the OS.
/SYS/SERVICE
Indicator Fault-Service Required LED Color: Amber
Location: Front and back panels
Off: Normal
On: Server requires service.
/SYS/LOCATE
Indicator Locate Button/LED Color: White
Location: Front and back panels
Off: Normal
Fast blink: Locate function is
activated; self-extinguishes after
30 minutes.
/SYS/PS_FAULT
Indicator Rear Power Supply Fault LED Color: Amber
Location: Front panel
Off: Normal
On: General power supply fault
/SYS/FAN_FAULT
Indicator Top Fan Fault LED Color: Amber
Location: Front panel
Off: Normal
On: General fan fault
/SYS/
DO_NOT_SERVICE
Indicator Do Not Service LED
Color: White
Location: Front panel
Off: Normal
On: Do not service this cell
Power Unit Components
The following table lists the power unit components.
Appendix E
Power Unit Components
E-2
