If the Oracle ILOM SP stops running and you cannot reset it using the Oracle ILOM web
interface or the Oracle ILOM CLI, use the following procedure to reset the SP from the server
back panel.
1. Locate the SP reset pinhole button on the server back panel.
Callout Description Icon
1 SP Reset button
2. Insert a non-conductive stylus straight into the SP reset pinhole no more than 6.5 mm
(the distance to reach and depress the reset button).
Care should be taken to not insert the stylus at an angle, to over penetrate, or
accidentally touch the sensitive electrical components near the button. The stylus must
be non-conductive with a diameter no more than 1.5 mm. To depress the pinhole button,
the stylus must reach 6.5 mm into the chassis.
3. After initiating the SP reset, the OK LED will fast blink while the SP is rebooting.
This can take a few minutes. The host will still operate normally.
Note:
Any Oracle ILOM user sessions running on the SP will be terminated during SP
reset. Once the SP has rebooted successfully, you will be able to log into
Oracle ILOM.
4. After the SP successfully boots, the LED will remain steady on.
You can confirm that the SP is working by logging into Oracle ILOM for that system.
For details, refer to Oracle ILOM Documentation.
Accessing Oracle ILOM
You can connect to Oracle ILOM using one of these methods:
• Serial remote host console – Access the host console remotely
• Serial connection to SER MGT port (CLI only) – Oracle ILOM command-line interface
(CLI) locally using the RJ-45 serial management port (SER MGT)
• Dedicated remote network management connection – Oracle ILOM CLI or Oracle
ILOM web interface remotely using a network port on the server (NET MGT)
Chapter 2
Accessing Oracle ILOM
2-17
