Note:
NVMe storage drives are supported only on servers that are running Oracle
Linux, Oracle Solaris, or Microsoft Windows Server.
– Removing and Replacing an NVMe Storage Drive Using Oracle Solaris
– Removing and Replacing an NVMe Storage Drive Using Oracle Linux
– Removing and Replacing an NVMe Storage Drive Using Microsoft Windows
Server
4. Push the latch release button to open the drive latch [1, 2].
Callout Description
1 Pressing the latch release button.
2 Opening the latch.
Caution:
The latch is not an ejector. Do not open the latch too far to the right. Doing so
can damage the latch.
5. Grasp the latch and pull the drive out of the drive slot.
Chapter 4
Remove a Storage Drive
4-3
