PG D
RIVES
T
ECHNOLOGY
O
MNI
– A
DVANCED
-P
ROGRAMMING
SK78813/5
3 Enable all Modes in the first SID 2 Profile.
4 Set the Profile names.
The Omni should now be programmed to suit the user and the SID, as
explained in the Standard section.
4 Using the Omni with Two SIDs and in
Conjunction with a Standard JSM
Refer to the sections Profiles and Modes Explained, Input Devices Explained
and Configuration Explained in the R-net PC Programmer help text or in the R-
net Technical Manual Programming chapter.
This is essentially a combination of the previous two examples.
There are five programming steps to follow:
1 Decide which Profiles are to be associated with the JSM and which
Profiles are to be associated with the Omni, and set the parameter
Input Device Type accordingly.
2 Decide which Profiles are to be associated with each SID and into
which Port each SID will connect, then set the parameter Port
accordingly.
3 Set the parameter Profile Enable to enable only the required Profiles.
4 Ensure the parameter Mode Enable is set to enable the required
Modes for the JSM and both SIDs.
5 Decide upon appropriate names for each of the Profiles and set the
parameter Profile Name accordingly.
Example:
Example: Example:
Example:
It is required that a standard JSM controls Profiles 1 and 2, and that the Omni
controls Profiles 3 to 6. Of the Omni Profiles, 3 and 4 will be controlled by SID 1
connected to Port 1, while Profiles 5 and 6 will be controlled by SID 2
connected to Port 2. All Modes can be controlled by the JSM and each of the
SIDs. Profiles are to be named JSM Slow, JSM Fast, SID1 Slow, SID1 Fast, SID2
Slow and SID2 Fast.
