PG Drives Technology R-NET OMNI - 6 Sip and Puff Input

PG D RIVES T ECHNOLOGY O MNI – S PECIFICATIONS
SK78813/5
166
High signal > 4.0V
Impedance: 10KΩ to 5V
6 Sip and Puff Input
This section refers to the pneumatic inlet on the underside of the Omni Module.
See the connections diagram in chapter 1 for more details.
Approximate pressure levels for full hard sips and puffs are:
Full puff 1PSI or 69mbar
Full sip -1.2PSI or –83mbar
