PG Drives Technology R-NET OMNI User Manual

PG D RIVES T ECHNOLOGY O MNI – S TANDARD - O PERATION
SK78813/5
41
1 General Operating Principles
When the Omni is powered-up or awoken, then a screen such as below will
appear. Power-up can be via the On/Off button on the front panel or via a
switch connected into the External On/Off Switch Jack; while wake-up can be
via the User Switch or a particular SID sequence if a User Switch is not fitted. See
section Using the Omni without a User Switch for details of this sequence.
This is a typical screen. Depending on SID type,
programming or system configuration and status,
there may be additional icons. Refer to section LCD
Screen Details for further information.
The wheelchair can now be driven with the SID. While driving, the speed of the
wheelchair will be indicated by the numeric display and the graphical display.

PG Drives Technology R-NET OMNI Specifications

General

Brand	PG Drives Technology
Model	R-NET OMNI
Category	Wheelchair
Language	English
