PG D RIVES T ECHNOLOGY O MNI – S TANDARD - O PERATION
SK78813/5
57
Left drive.
Mode Select
11.3.10 Scanner Actuator Symbols
If the Omni is programmed to operate with a Single Switch Scanner Type SID
these symbols will be displayed to indicate:
Up.
Down.
Exit Actuators
:: Mode Screens ::
11.3.11 Actuator Mode
