PG D
RIVES
T
ECHNOLOGY
O
MNI
– D
IAGNOSTICS
SK78813/5
If the trip is still present after the above has been attempted, then the Omni
may be defective. Refer to Section 5.
3.8 Latched Timeout
This occurs when the control system detects that the Latched Timeout
programmed time has been exceeded. For example, the Input Device,
Joystick, Head Array, Sip and Puff, etc. has not been operated frequently
enough.
The trip is a notification of why the control system has dropped out of Latched
Mode.
• Cycle the power.
• Initiate Latched Mode.
If the trip is still present after the above checks have been made, then the Input
Device may be defective. Refer to Section 5.
3.9 Brake Lamp Short
This occurs when the control system detects a short in the Brake Lamp Circuit.
Refer to section 2.3 for connection details.
• Check the brake lamps, cables and connections to the control
system.
If the trip is still present after the above checks have been made, then the ISM
may be defective. Refer to Section 5.
3.10 Lamp Short
This occurs when the control system detects a short in either of the Lamp
Circuits. Refer to section 2.3 for connection details.
7205 - Left Lamp Short
7209 - Right Lamp Short
• Check the lamps, cables and connections to the control system.
If the trip is still present after the above checks have been made, then the ISM
may be defective. Refer to Section 5.
