PG D
RIVES
T
ECHNOLOGY
O
MNI
– S
PECIFICATIONS
SK78813/5
165
34 Pins 7 and 9 – 12V 100mA
These pins are connected together inside the Omni and provide a 12V supply
to the input device. The total combined current capability is 100mA.
3.5 Pin 8 – 0V
A 0V supply for the input device.
4 User Switch
This section refers to the 3.5mm/1/8” jack sockets on the underside of the Omni
See the connections diagram in chapter 1 for more details.
If the Omni is configured for a normally closed User switch, there should be a
permanent low signal and a high signal will be interpreted as a switch
operation. If the Omni is configured for a normally open User switch, the
opposite will apply.
4.1 Signal levels
Low signal < 0.8V
High signal > 4.0V
Impedance: 10K to 5V
5 On/Off Switch
This section refers to the 3.5mm/1/8” jack socket on the underside of the Omni.
See the connections diagram in chapter 1 for more details.
A normally open switch should be connected. A low signal is interpreted as a
switch transition and will switch the Omni on or off.
5.1 Signal levels
Low signal < 0.8V
