PG D
RIVES
T
ECHNOLOGY
O
MNI
– S
TANDARD
- I
NSTALLATION
SK78813/5
The SID’s D-type connector should always be fitted
with gold contacts and a suitable backshell with
locking screws. The locking screws should be used to
mechanically hold the connector in place. PG Drives
Technology accept no liability for losses of any kind if
these conditions are not met.
6.4 Sip and Puff Input
Ensure the tube from the Sip and Puff Device is of the correct diameter and that
it is securely routed. For pneumatic details of this input, refer to the
Specifications Chapter.
7 How to set up the Omni
There are three methods of programming the Omni. Details of the actual
programmable parameters are given in the Programming chapter.
7.1 On-Board Programming (OBP)
This is performed using the Omni’s own display and front panel buttons. For
details of these buttons, refer to section Controls and Connections. From the
Omni, all system OBP parameters can be adjusted: for example, Speeds and
Accelerations.
OBP can be entered in one of two ways, depending on the factory
programming of the control system.
7.1.1 To enter OBP using a keypad sequence:
• Hold down the Profile button and then hold down the On/Off
button until there is a short beep. Note, the normal power-up
sound will occur prior to this beep.
• Release the Profile button, but continue to hold down the On/Off
Button until there are two further short beeps.
• Release the On/Off button, there will be a longer beep and OBP
Mode will be entered.
