PG D
RIVES
T
ECHNOLOGY
O
MNI
– D
IAGNOSTICS
SK78813/5
R Ind Lamp Short Refer to section 3.11
L Ind Lamp Failed Refer to section 3.12
R Ind Lamp Failed Refer to section 3.12
Over-current Refer to section 3.13
Overtemp. (Acts) Refer to section 3.14
Overtemp. (Lamps) Refer to section 3.15
DIME Error Refer to section 3.16
Memory Error Refer to section 3.17
PM Memory Error Refer to section 3.18
Bad Cable Refer to section 3.19
Bad Settings Refer to section 3.20
Module Error Refer to section 3.21
System Error Refer to section 3.22
SID Detached Refer to section 3.23
User Switch Detached Refer to section 3.24
Over Pressure Refer to section 3.25
Gone to Sleep Refer to section 3.26
Charging Refer to section 3.27
3.1 Center Joystick
The most common cause of this trip is if the SID is deflected away from center
before and during the time the control system is switched on. The joystick
displaced screen will be displayed for 5 seconds, if the SID is not released within
that time then a trip is registered. Although a trip screen is not displayed the
system log will show the trip and numbers of occurrences.
• Ensure that the SID is centered and power-up the control system.
If the trip is still present then the SID or Omni may be defective.
