PG Drives Technology R-NET OMNI User Manual

PG D RIVES T ECHNOLOGY O MNI – S PECIFICATIONS
SK78813/5
164
2.4 Pin 5 – Detect
This pin should be linked to 0V inside the input device. This link allows the Omni
to detect if the SID is connected. If the link is not fitted, the Omni should be
configured to ignore the absence of the link.
2.5 Pins 7 and 9 – 12V 100mA
These pins are connected together inside the Omni and provide a 12V supply
to the joystick. The total combined current capability is 100mA.
2.6 Pin 8 – Joystick ground
A 0V supply for the joystick.
3 Digital Signal Levels
3.1 Pins 1,2,3 and 4 - Direction
Low signal < 0.7V
High signal > 1.4V
Impedance: 132KΩ to 3V
3.2 Pin 6 – Fifth Switch
Low signal < 0.7V
High signal > 1.4V
Impedance: 100KΩ to 5V
3.3 Pin 5 – Detect
This pin should be linked to 0V inside the input device. This link allows the Omni
to detect if the input device is connected. If the link is not fitted, the Omni
should be configured to ignore the absence of the link.
