PG Drives Technology R-NET OMNI - Connections

PG D RIVES T ECHNOLOGY O MNI – D IAGNOSTICS
SK78813/5
140
2.3 Connections
The R-net has various connections that are referred to by the diagnostic text.
These connections can be on the Power Module(PM), Joystick Module(JSM), the
Intelligent Seating/Lighting Module(ISM) and the Omni. The following diagrams
show the connections on these Modules.
