PG Drives Technology R-NET OMNI User Manual

PG D RIVES T ECHNOLOGY O MNI – S TANDARD - P ROGRAMMING
SK78813/5
72
To enter OBP using the R-net Dongle:
• Turn off the control system.
• Connect the Dongle either between any of the system modules or
into any spare communications connector.
• Turn on the control system.
• Use the Mode button to step to the OBP mode.
While the Dongle remains connected, the Mode button can be used to
sequence through all system Modes and to return to OBP Mode.
The following parameters are available for adjustment within OBP. Within the
OBP parameter tree, there is a branch called Omni. This branch contains the
parameters shown below. The default settings for all these parameters are also
shown below. Refer to the R-net OBP user guide for details of how to program
using this method. Those marked with * are relevant to advanced use and you
should read the Advanced Section of this document before making
adjustments.
1.1.1 OBP Parameter List
Global
GlobalGlobal
Global
Sip and Puff
Calibrate Test Function
Puff Threshold 50%
Sip Threshold 50%
Deadband 10%
Puff Ramp Up 0.30s
Puff Ramp Down 0.30s
Sip Ramp Up 0.30s
Sip Ramp Down 0.30s
Double Click 2xSoft
Double Click Time 1.0s
Active Double Click Test Function
Scan Speed 1.0s
Sleep 12V On
Profiled
ProfiledProfiled
Profiled
Port 1
