PG D
RIVES
T
ECHNOLOGY
O
MNI
– S
TANDARD
- I
NSTALLATION
SK78813/5
2.1 LCD Screen
A full color, backlit LCD screen that can show Omni configuration details and
operating information to the installer and user. More details of actual displays
are given in the LCD Screen Details Section and throughout this manual.
2.2 On/Off Button
The On/Off button provides a complete power down of the control system
electronics. In addition to the button mounted on the front panel of the Omni
Module, there is facility for an optional, externally mounted switch which can be
operated by the user, see section External On/Off Switch Input.
2.3 Mode Button
The Mode button allows the installer to change between the available Modes.
2.4 Profile Button
The Profile button allows the installer to change between the available Drive
Profiles.
2.5 Navigation Buttons
The array of 4 Navigation buttons allows the OBP screens to be navigated.
2.6 - / + Buttons
These buttons make adjustments to the highlighted OBP parameter.
Holding both buttons down at the same time launches the Omni into the
Settings menu screen.
2.7 Charger Socket
This 3pin socket can be used to charge the wheelchair batteries and,
dependent on system programming, to lock the wheelchair. For details of
battery charging, refer to the R-net Operating and Installation guide.
