To begin the procedure you must first enter OBP mode and go to the System
branch. Select the Joystick Calibration option.
The procedure is automatic, simply follow the on-screen instructions. Values for
both the forward/reverse and left/right SID axes will be displayed. Alongside
each value will be a X
XX
X or a √
√√
√ symbol.
X
XX
X – indicates the axis value is outside of the permitted calibration range
for the particular SID direction.
√
√√
√ – indicates the axis value is within the permitted calibration value for
the particular SID direction.
Simply deflect the SID in the instructed direction until both values are within the
permitted ranges. Repeat for all four directions.
A large tick will be displayed on screen, for a short period of time, when the
calibration has been completed successfully. The screen will then return to the
System Menu.
8.2 Five switch and User Switch
Typical applications are Tash Penta switches or Buddy Buttons, or products from
ASL and Switch-it.
The device comprises of 4 direction switches and one User switch connected to
the Omni via the 9-way D-type connector. In addition, a normally closed User
Switch should be connected to the Omni via the 3.5mm/1/8” jack socket. This
switch, although functionally identical to the fifth switch input on the 9-way D-
type connector, is required to provide a fail-safe emergency stop system.
8.3 Three axis proportional and User Switch
Typical applications are head control mechanisms fitted with a joystick.
The device comprises of a PG Drives Technology or Flightlink type inductive
joystick connected to the Omni via the 9-way D-type connector. In addition, a
User Switch is required and connects to the Omni via the 3.5mm/1/8” jack
socket.
8.4 Three axis switch and User Switch
Typical applications are head control systems.
