Philips HeartStart XL+ - Installing Software

Internal Assemblies — Front Chassis 4: Repair
139
7 Scroll through the list and select Done when you have finished entering the serial number.
CAUTION: Once you have entered the correct serial number, do not change it. If you clear or change the serial
number, the options are cleared and you must re-enter the correct serial number and the options key.
Installing Software
See “Software Upgrades” on page 11 for details on software installation.
 To install software onto the device or to change the device’s language:
1 Be sure both an AC power module and battery charged to at least 20% are in place.
2 Tu r n th e Th er a py Kn o b t o Monitor.
3 Enter the Service Mode
4 Insert the Software Support flash drive into the USB port.
5 From the Service Mode Main menu, select Device Info.
6 From the Service Mode Main menu, select Software Upgrade.
Make sure the software release and language displayed on the screen are correct.
7 Press the
Upgradesoft key. The software installation starts.
CAUTION: After the upgrade start, be careful not to interrupt the software installation process by removing the USB
flash drive or power source or turning the Therapy Knob.
8 The software is installed on the device. This process takes a few minutes. While the software is being
updated, progress messages are displayed and the soft keys are disabled.
9 When the software or language installation process is complete, turn the device off and on.
10 Remove the Software Support flash drive from the USB port.
Figure 94 Software Upgrade Progress Screen









