Overview 4: Repair
71
Disposal
Prior to disposal, remove the external and internal batteries. Then dispose of the device in accordance
with your country’s regulations for equipment containing electronic parts.
WARNING: To avoid contaminating or infecting personnel, the environment, or other equipment, make sure you
disinfect and decontaminate the defibrillator/monitor appropriately prior to disposal.
Properly dispose or recycle depleted batteries according to local regulations. Do not puncture,
disassemble, or incinerate batteries. Be careful not to short the battery terminals because this could result
in a fire hazard. Disposal of the device with the battery inserted presents a potential shock hazard.
Repair Tools and Equipment
The following tools are needed to perform the procedures in this chapter:
• Torx T10, T15, and T-20 drivers (or Torx driver kit). T15 driver shaft should be less than 0.4-inches
(10 mm) in diameter to reach down to recessed handle screws.
TIP: You need the T-20 driver only for the Paddle Tray and Plates replacement.
• Slip-joint pliers or adjustable open-end wrench.
• open-jaw 1 1/8" (29-mm) or adjustable wrench for the Therapy Port replacement.
• Straight-tip needle-nose pliers or tweezers.
• Bent-tip needle-nose pliers whose jaws are covered with a soft material (e.g. plastic tubing or tape).
• Utility knife.
• Wire cutter.
• Four pins of no more than 1/8" (3 mm) in diameter to support the Rear Chassis in removal and
replacement procedures. T15 and smaller screwdrivers may be used.
• Software Support tool for upgrades and Processor PCA repairs (see Table 39“Software Support Tool”
on page 176 for part numbers).
• Defibrillator Discharge Tool (M2475-69573).
• Gloves and ESD protection for PCA handling.
