Performance Verification Procedures 5: Performance Verification
167
Check ECG Printing
1 Reconnect the simulator to the device as described in the Setup section above.
2 Press the Print button to print a strip.
a Verify that it shows a normal ECG with a clean baseline.
b Verify that the date, time, and configuration information printed at the top of the strip are
correct.
3 Press the Print button again to stop printing.
SpO
2
Check
NOTE: A functional tester (i.e. simulator or safety analyzer) can not be used to assess the accuracy of an SpO
2
probe or an SpO
2
monitor.
1 Connect the sensor.
Attach the SpO
2
sensor to your finger and to the HeartStart XL+.
2 Tu r n th e Th er a py Kn o b t o Monitor. Observe:
a The pleth wave is clear.
b The SpO
2
value displayed is in the range of 95-100%. If the value is less than 95%, check that
your finger is fully inserted into the sensor and properly positioned.
c The pulse rate is displayed.
NBP Check
1 Perform a non-invasive blood pressure check on yourself or another person.
2 Make sure the measurement completes.
3 Perform the NBP module tests only if you suspect a problem with the module. See “NBP Module
Te s t s” on page 22 for information on these tests.
Defibrillator Measurement Test
These instructions describe how to test the defibrillation functions. The test sequence causes the
HeartStart XL+ to:
• Charge and deliver a shock when powered by AC power alone.
• Charge and deliver a shock when powered by battery alone.
•Disarm when the Disarm soft key is pressed.
If all results are as described, the device passes that portion of the test. If there is any failure, troubleshoot
and repair the device as needed. See “Troubleshooting” on page 29.
