Philips HeartStart XL+ - Test and Inspection Matrix

Test and Inspection Matrix 5: Performance Verification
157
Test and Inspection Matrix
Tab le 3 7 summarizes Performance Verification tests and inspections for the HeartStart XL+.
Table 37 Test and Inspection Matrix
Tes t Gro up
Name
Test or Inspection to Perform Expected Test Results Data to Record
x = p (pass)
or f (fail)
Visual Insp.
(V)
Inspect the device, accessories, cables, etc.,
see “Visual Inspection” on page 160.
If no unusual damage, no missing items,
then Visual Inspection passes.
V:x
Example V:p
Service Mode Tests
Operational
Check (OC)
Run the Op Check. See “Operational
Check” on page 161.
If “Pass” reported on all tests applicable to
the device configuration and options, then
Op Check passes.
OC:x
Example OC:p
Error Logs
(EL)
Check the Error Logs after the
Operational Check. See “Error Log
Messages” on page 41.
If no critical errors after the last successful
Op Check, then Error Logs pass.
EL:x
Example EL:p
Controls test
(C)
Run test to check buttons, Therapy Knob,
Functional Keys, and soft keys. See
“Controls Test” on page 162.
If all keys respond as expected, then
Controls test passes.
C:x
Example C:p
Display (DP) Run Display test. See “Display Test” on
page 163.
If pattern displays correctly, then Display
test passes
DP:x
Example DP:p
Fan (F) Run Fan test. See “Fan Test” on page 164. If test passes, Fans pass. F:x
Example F:p
Printer (Pr) Run Printer test. See “Printer Test” on
page 164.
If print quality is adequate; no stray marks
or lines and print speed: 25 mm
± 5% (1.25
mm) then Printer test passes.
Pr:x
Example Pr:p
USB (USB) Run USB test. See “USB Test” on
page 165.
If test passes, USB passes. USB:x
Example USB:p
NBP Cal
Check (NC)
Run the “NBP Module Tests” on page 22. If all data passes within limits, then NBP
calibration check passes.
NC:x
Example N:p
Functional Checks: In normal Clinical Mode, perform the following functional checks:
ECG (E) Using an ECG simulator, perform Leads
ECG and Pads cable ECG test. See “ECG
Check” on page 166.
If all checks pass, and all data within limits:
• Waveform clear on display
• HR correct on display and matches defib
analyzer at 2 data points: 30 and 200 bpm
• HR alarm works
• Leads off indicators perform as expected
• Cycles through different views
then ECG test passes.
E:x
Example E:p
SpO
2
(Sp) Using the SpO
2
sensor, perform SpO
2
check. See “SpO2 Check” on page 167.
If pleth wave is clear, pulse rate is displayed,
and saturation reads between 95% -100%,
then SpO
2
check passes.
SP:x
Example Sp:p
